Sunex is a leading provider of lenses for OEM rear view
cameras. Although, the market for rear view cameras is the most mature of
all the automotive vision applications, OEMs demand technical
and commercial improvements with every succeeding camera generation. Sunex product offerings continue to grow
with better performing and more cost-effective solutions. We have comprehensive selection of
wide-angle lenses designed specifically for automotive qualified
image sensors such as those offered by Aptina and
Omnivision. Technically, rear view
lenses present many challenges due to the end user requirements for
good color fidelity and high resolution along with wide-angle
field of view and low-light performance. Sunex
Tailored Distortion™,
even without electronic distortion correction offers a clear
advantage over standard distortion lenses.
See the comparison image below. With Tailored Distortion™ the
end-user sees a parking space whose relative size and position
is more correct, easing the delicate effort of parking.
With the market trend toward increasing
FOV for a single camera and multiple camera systems, Sunex
offers unmatched miniature fisheye and
SuperFisheye (>185deg) lenses
with low f/#. The latest lens,
DSL216, gives 187deg FOV with F/2.0 in a rugged package and was designed
specifically for automotive vision applications.
Sunex off-the-shelf solutions listed below are often a good
starting point to develop a custom OEM solution. If you
cannot find the product that exactly meets your requirements, please
contact us.
| PN |
Description |
Focal length(mm) |
f/# |
Imager
Format |
Field of view/
Depth of field |
Recommended Holder
|
Sample Price (1-99) |
Volume Price |
 DSL218A-NIR-F2.0
|
Miniature super fisheye lens, no IR cut filter, EFL = 1.2mm, F/2.0, M12x0.5, metal barrel ***C-mount adapter available! CMT1205-C***. Distortion dewarping software available.
|
1.2
|
2
|
various
|
Calculate FOV
Calculate DOF |
CMT821, CMT002
|
$99
Order Sample |
Request Volume Quote |
| DSL218A-670-F2.0
|
Miniature super fisheye lens, with IR cut filter, EFL = 1.2mm, F/2.0, M12x0.5, metal barrel ***C-mount adapter available! CMT1205-C***. Distortion dewarping software available.
|
1.2
|
2
|
various
|
Calculate FOV
Calculate DOF |
CMT821, CMT002
|
$99
Order Sample |
Request Volume Quote |
| DSL236E-670-F2.0
|
Wide-angle hybrid lens for OV9715. EFL=1.23, F/2.0; Plastic barrel, aluminum cap; Decentration <1.0; Sealed; HP coating on L1-S1; Laser engraved PN, mark on retaining cap
|
1.23
|
2
|
1/4"
|
Calculate FOV
Calculate DOF |
|
$69
Order Sample |
Request Volume Quote |
| DSL216A-670-F2.8
|
Miniature super fisheye lens with IR cut coating, EFL = 1.3mm, F/2.8, M12x0.5, metal barrel, UV-anodize, sealed first element***C-mount adapter available! CMT1205-C***. Distortion dewarping software available.
|
1.26
|
2.8
|
various
|
Calculate FOV
Calculate DOF |
CMT821, CMT002
|
$99
Order Sample |
Request Volume Quote |
| DSL216A-670-F2.0
|
Miniature super fisheye lens with IR cut coating, EFL = 1.3mm, F/2.0, M12x0.5, metal barrel ***C-mount adapter available! CMT1205-C***. Distortion dewarping software available.
|
1.26
|
2
|
various
|
Calculate FOV
Calculate DOF |
CMT821, CMT002
|
$99
Order Sample |
Request Volume Quote |
| DSL217D-NIR-F1.8
|
Miniature SuperFisheye lens for megapixel imagers up to 1/3” format. EFL=1.3mm, relative aperture F/1.8, no IR cut-off filter, metal barrel threaded M12x0.5
|
1.3
|
1.8
|
various
|
Calculate FOV
Calculate DOF |
|
$99
Order Sample |
Request Volume Quote |
| DSL217C-650-F1.8
|
Miniature super fisheye lens, IR cut-off at 650nm, EFL = 1.3mm, F/1.8, M12x0.5, sealed IP6K9K, metal barrel ***C-mount adapter available! CMT1205-C***. Distortion dewarping software available.
|
1.3
|
1.8
|
various
|
Calculate FOV
Calculate DOF |
CMT821, CMT002
|
$99
Order Sample |
Request Volume Quote |
| DSL217C-NIR-F1.8
|
Miniature super fisheye lens, no IR cut filter, EFL = 1.3mm, F/1.8, M12x0.5, sealed IP6K9K, metal barrel ***C-mount adapter available! CMT1205-C***. Distortion dewarping software available.
|
1.3
|
1.8
|
various
|
Calculate FOV
Calculate DOF |
CMT821, CMT002
|
$99
Order Sample |
Request Volume Quote |
| DSL217C-670-F1.8
|
Miniature super fisheye lens, IR cut-off at 670nm, EFL = 1.3mm, F/1.8, M12x0.5, sealed IP6K9K, metal barrel ***C-mount adapter available! CMT1205-C***. Distortion dewarping software available.
|
1.3
|
1.8
|
various
|
Calculate FOV
Calculate DOF |
CMT821, CMT002
|
$99
Order Sample |
Request Volume Quote |
| DSL209K-650-F2.0-HP3
|
Wide-angle glass lens for ¼” sensor, IR cut at 650nm, EFL=1.7, F/2.0, M12x0.5, UV anodize, sealed IP6K9K, HP3 coating
|
1.7
|
2
|
1/4"
|
Calculate FOV
Calculate DOF |
|
$69
Order Sample |
Request Volume Quote |
| DSL209A-650-F2.0
|
Wide-angle glass lens with IR cut-off coating for 1/4" sensor, EFL=1.7mm, F/2.0, M12x0.5. Distortion dewarping software available.
|
1.7
|
2
|
1/4"
|
Calculate FOV
Calculate DOF |
CMT821, CMT804
|
$69
Order Sample |
Request Volume Quote |
| DSL212F-645-F3.0
|
Wide-angle glass lens for 1/3" sensor, IR-cut coating at 645nm, EFL=1.97mm, F/3.0, aluminum barrel threaded M12x0.5
|
1.97
|
3
|
1/3"
|
Calculate FOV
Calculate DOF |
|
$69
Order Sample |
Request Volume Quote |
| DSL212D-650-F3.0
|
Wide-angle glass lens for 1/3" sensor, with integrated IR cut-off filter, EFL=1.97mm, F/3.0, aluminum barrel threaded M12x0.5
|
1.97
|
3
|
1/3"
|
Calculate FOV
Calculate DOF |
CMT821, CMT002
|
$69
Order Sample |
Request Volume Quote |
| DSL212D-NIR-F3.0
|
Wide-angle glass lens for 1/3" sensor, NO IR cut-off filter, EFL=1.97mm, F/3.0, aluminum barrel threaded M12x0.5
|
1.97
|
3
|
1/3"
|
Calculate FOV
Calculate DOF |
CMT821, CMT002
|
$69
Order Sample |
Request Volume Quote |
| DSL224D-NIR-F2.0
|
Wide-angle glass lens for 1/3" sensor, NO IR cut-off filter, EFL=2.16mm, F/2.0, aluminum barrel threaded M12x0.5
|
2.16
|
2
|
1/3"
|
Calculate FOV
Calculate DOF |
CMT821, CMT002
|
$69
Order Sample |
Request Volume Quote |
| DSL224D-670-F2.0
|
Wide-angle glass lens for 1/3" sensor, with integrated IR cut-off filter at 670nm, EFL=2.16mm, F/2.0, aluminum barrel threaded M12x0.5
|
2.16
|
2
|
1/3"
|
Calculate FOV
Calculate DOF |
CMT821, CMT002
|
$69
Order Sample |
Request Volume Quote |
| DSL224D-650-F2.0
|
Wide-angle glass lens for 1/3" sensor, with integrated IR cut-off filter at 650nm, EFL=2.16mm, F/2.0, aluminum barrel threaded M12x0.5
|
2.16
|
2
|
1/3"
|
Calculate FOV
Calculate DOF |
CMT821, CMT002
|
$69
Order Sample |
Request Volume Quote |
Didn’t find the lens you’re looking for? Try searching our
entire lens database using one of the following options:
|
