Whether you need a Day/Night, high-resolution lens for
Surveillance, a low-light, ultra-compact lens for
Access Control or a high-resolution, finite imaging lens for
Biometric Recognition, Sunex has your solution. Sunex Security lenses are designed to meet the special needs of these demanding applications. With wide field of view options up to 190deg and high performance features, these lenses are also a fraction of the cost of similar lenses on the market. Designed for CMOS or CCD imagers up to ½” format and multi-megapixel resolutions up to 10mp, there is a lens option to suite your needs. The board-mount format of Sunex lenses also means smaller size for discrete, compact camera designs. And if all of this is not enough, Sunex has the expert staff, experience and capability to design a lens to your exact requirements.
- Wide-angle field of view from 74° to fisheye [190°]
- High image quality suitable for Megapixel CMOS/CCD sensors
- HDR Optimized lenses
- Extremely compact mechanical design
- Low cost alternative to C-mount lenses
List of products by category:
| PN |
Description |
Focal length(mm) |
f/# |
Imager Format |
Field of view/
Depth of field |
Recommended Holder
|
Sample Price (1-99)
|
Volume Price |
 DSL133A-650-F2.0-HP3
|
Superfisheye, HDR and environmentally stable lens for 1/4" format sensors, EFL=0.88, F/2.0, M12x0.5
|
0.88
|
2
|
1/4"
|
Calculate FOV
Calculate DOF |
CMT168
|
$69
Order Sample | Request Volume Quote |
| DSL188A-650-F2.0
|
Superfisheye, hybrid, for 1/4" sensors, HDR, 0.94mm EFL, 4.0mm image circle, F/2.0. Aluminum barrel threaded M12x0.5. IR Cut filter at 650nm.
|
0.94
|
2
|
1/4"
|
Calculate FOV
Calculate DOF |
|
$69
Order Sample | Request Volume Quote |
| DSL188A-NIR-F2.0
|
Superfisheye, hybrid, for 1/4" sensors, HDR, 0.94mm EFL, 4.0mm image circle, F/2.0. Aluminum barrel threaded M12x0.5. IR Cut filter at 650nm.
|
0.94
|
2
|
1/4"
|
Calculate FOV
Calculate DOF |
|
$69
Order Sample | Request Volume Quote |
| DSL180B-690-F2.0
|
Miniature tailored distortion fisheye lens, with IR cut filter, EFL=0.97mm, F/2.0, M12x0.5 slipfit, metal barrel. Compatible with CMT168.
|
0.97
|
2
|
1/4"
|
Calculate FOV
Calculate DOF |
CMT168-1122F
|
$69
Order Sample | Request Volume Quote |
| DSL180A-NIR-F2.0
|
Miniature tailored distortion fisheye lens, without IR cut filter, EFL=0.97mm, F/2.0, M12x0.5, metal barrel. Compatible with CMT821.
|
0.97
|
2
|
1/4"
|
Calculate FOV
Calculate DOF |
CMT821, CMT002
|
$69
Order Sample | Request Volume Quote |
| DSL180A-690-F2.0
|
Miniature tailored distortion fisheye lens, with IR cut filter, EFL=0.97mm, F/2.0, M12x0.5, metal barrel. Compatible with CMT821.
|
0.97
|
2
|
1/4"
|
Calculate FOV
Calculate DOF |
CMT821, CMT002
|
$69
Order Sample | Request Volume Quote |
| DSL145A-650-F2.0-HP3
|
Superfisheye, HDR and environmentally stable lens for 1/4" format sensors, EFL=0.97, F/2.0, M12x0.5
|
0.97
|
2
|
1/4"
|
Calculate FOV
Calculate DOF |
CMT168
|
$69
Order Sample | Request Volume Quote |
| DSL180B-NIR-F2.0
|
Miniature tailored distortion fisheye lens, without IR cut filter, EFL=0.97mm, F/2.0, M12x0.5 slipfit, metal barrel. Compatible with CMT168.
|
0.97
|
2
|
1/4"
|
Calculate FOV
Calculate DOF |
CMT168-1122F
|
$69
Order Sample | Request Volume Quote |
| DSL367B-650-F2.1
|
Superfisheye, hybrid, for 1/4" sensors, HDR, 0.98mm EFL, 4.2mm image circle, 210° FOV, F/2.1. Aluminum barrel threaded M12x0.5. IR Cut filter at 650nm.
|
0.98
|
2.1
|
1/4"
|
Calculate FOV
Calculate DOF |
|
$69
Order Sample | Request Volume Quote |
| DSL367B-NIR-F2.1
|
Superfisheye, hybrid, for 1/4" sensors, HDR, 0.98mm EFL, 4.2mm image circle, 210° FOV, F/2.1. Aluminum barrel threaded M12x0.5. NO IR Cut filter.
|
0.98
|
2.1
|
1/4"
|
Calculate FOV
Calculate DOF |
|
$69
Order Sample | Request Volume Quote |
| DSL198A-650-F2.0
|
Superfisheye lens, HDR, 1.03mm EFL, 4.0mm image circle, 214deg FOV, F/2.0. Aluminum barrel threaded M12x0.5. IR Cut Filter at 650nm.
|
1.03
|
2
|
1/4"
|
Calculate FOV
Calculate DOF |
|
$69
Order Sample | Request Volume Quote |
| DSL198A-NIR-F2.0
|
Superfisheye lens, HDR, 1.03mm EFL, 4.0mm image circle, 214deg FOV, F/2.0. Aluminum barrel threaded M12x0.5. NO IR Cut Filter.
|
1.03
|
2
|
1/4"
|
Calculate FOV
Calculate DOF |
|
$69
Order Sample | Request Volume Quote |
| DSL218A-NIR-F2.0
|
Miniature super fisheye lens, no IR cut filter, EFL = 1.2mm, F/2.0, M12x0.5, metal barrel ***C-mount adapter available! CMT1205-C***. Distortion dewarping software available.
|
1.2
|
2
|
various
|
Calculate FOV
Calculate DOF |
CMT821, CMT002
|
$99
Order Sample | Request Volume Quote |
| DSL218A-670-F2.0
|
Miniature super fisheye lens, with IR cut filter, EFL = 1.2mm, F/2.0, M12x0.5, metal barrel ***C-mount adapter available! CMT1205-C***. Distortion dewarping software available.
|
1.2
|
2
|
various
|
Calculate FOV
Calculate DOF |
CMT821, CMT002
|
$99
Order Sample | Request Volume Quote |
| DSL236E-670-F2.0
|
Wide-angle hybrid lens for OV9715. EFL=1.23, F/2.0; Plastic barrel, aluminum cap; Decentration <1.0; Sealed; HP coating on L1-S1; Laser engraved PN, mark on retaining cap
|
1.23
|
2
|
1/4"
|
Calculate FOV
Calculate DOF |
|
$69
Order Sample | Request Volume Quote |
| DSL181C-650-F2.2
|
Superfisheye lens, Tailored Distortion, HDR, EFL=1.25mm, 190deg HFOV, F/2.2, 4.8mm image circle. Aluminum barrel threaded M12x0.5. IR Cutoff Filter at 650nm.
|
1.25
|
2.2
|
1/3.2"
|
Calculate FOV
Calculate DOF |
|
$69
Order Sample | Request Volume Quote |
| DSL181B-650-F2.2
|
Miniature tailored distortion fisheye lens, with IR cut filter, EFL=1.25mm, F/2.2, M12x0.5 slipfit, metal barrel. Compatible with CMT168.
|
1.25
|
2.2
|
1/3.2"
|
Calculate FOV
Calculate DOF |
CMT168-1122F
|
$69
Order Sample | Request Volume Quote |
| DSL181B-NIR-F2.2
|
Miniature tailored distortion fisheye lens, without IR cut filter, EFL=1.25mm, F/2.2, M12x0.5 slipfit, metal barrel. Compatible with CMT168.
|
1.25
|
2.2
|
1/3.2"
|
Calculate FOV
Calculate DOF |
CMT168-1122F
|
$69
Order Sample | Request Volume Quote |
| DSL216A-670-F2.8
|
Miniature super fisheye lens with IR cut coating, EFL = 1.3mm, F/2.8, M12x0.5, metal barrel, UV-anodize, sealed first element***C-mount adapter available! CMT1205-C***. Distortion dewarping software available.
|
1.26
|
2.8
|
various
|
Calculate FOV
Calculate DOF |
CMT821, CMT002
|
$99
Order Sample | Request Volume Quote |
| DSL216A-NIR-F2.0
|
Miniature super fisheye lens, no IR cut coating, EFL = 1.3mm, F/2.0, M12x0.5, metal barrel ***C-mount adapter available! CMT1205-C***
|
1.26
|
2
|
various
|
Calculate FOV
Calculate DOF |
CMT821, CMT002
|
$99
Order Sample | Request Volume Quote |
|
