Auto-focus technology

Sunex has developed close relationships with the following world-class Autofocus providers.  Sunex can deliver fully integrated AF solutions based on your requirements and chosen AF technology.


http://www.varioptic.com

Varioptic is the pioneer and world leader in liquid lens technology; it enables fast focus, unlimited cycles, as well as unique shock resistance and low power consumption. This technology is widely used in industrial vision, barcode reading, medical imaging, biometrics… Its latest product enables tilt control in addition to focus control, enabling beam deviation and Optical Image Stabilization with absolutely no moving parts.

You can order the following off-the-shelf auto-focus lens modules with liquid lens technology:

PN Description Sample Price (1-99 pcs)
AFL944A-650-F3.0 Base lens DSL944 with EFL=7.5mm, and F/#=3 with IR cut-off coating $99, order online
AFL944A-NIR-F3.0 Base lens DSL944 with EFL=7.5mm, and F/#=3 without IR cut-off coating $99, order online
AFL935A-650 Base lens DSL935 with EFL=9.6mm, and F/#=3.8 with IR cut-off coating $99, order online
AFL935A-NIR Base lens DSL935 with EFL=9.6mm, and F/#=3.8 without IR cut-off $99, order online
AFL208A-650-F4 Base lens DSL208 with EFL=15.8mm, and F/#4.0 with IR filtering $99, order online
AFL208A-NIR-F4 Base lens DSL208 with EFL=15.8mm, and F/#4.0 without IR filtering $99, order online
